PARTS > MD MANUALS > 2006-03-01, 7000-9, Serial 79108-92036 > Power Deck Lift Kit:

Diagram #	Part #	Description	Price	Add to Cart
1	8628	Linear Actuator (10" OAL) (Includes Items # 29, 30 & F320)
2	8655-8	Clamp Bar	$10.82	Add to Cart
3	7503-10	Actuator Drive Bushing	$39.51	Add to Cart
4	8655-11	Bushing 58x516x1116	$13.53	Add to Cart
5	8655-10	Bushing 58x516x1116	$12.80	Add to Cart
6	8655-7	Arm Deck Lift	$18.59	Add to Cart
7	8655-9	Cable Pull	$9.84	Add to Cart
8	8655-12	Bushing 34x14x34	$14.72	Add to Cart
9	5977-1	Grommet 18x38	$0.79	Add to Cart
10	8649	Wire Harness Deck Lift	$21.21	Add to Cart
11	5975-5	Wire ClipSelfMount	$1.30	Add to Cart
12	6623	Toggle Switch	$37.09	Add to Cart
13	5996-21	1210 GA Ring Term 10 Insulated	$0.84	Add to Cart
14	8655-1	NR Hitch PinCottrless 58	$4.75	Add to Cart
15	8655-6	Lift Chain	$7.70	Add to Cart
16	8655-5	Cable Mount	$10.01	Add to Cart
17	5996-20	1210 GA Ring Term 14 Insulated	$0.96	Add to Cart
18	8942-3	5Way Connector M	$5.78	Add to Cart
19	5940-4	1614 GA Spg Ldd TermF	$1.67	Add to Cart
20	8655-3	NR CableLH 48	$138.39	Add to Cart
21	8655-2	NR CableRH 385	$156.66	Add to Cart
22	8654	NR Decal Deck Lift	$6.31	Add to Cart
23	6623-1	Switch Boot	$13.59	Add to Cart
24	6832	Cable Clamp 916x14	$1.32	Add to Cart
25	5832	Cable Clamp 12 203 Hole	$1.87	Add to Cart
26	8655-22	Base Deck Lift	$48.47	Add to Cart
27	8655-4	Clevis Pin 516x34	$1.06	Add to Cart
28	5975-3	Cable Tie 50x7	$0.36	Add to Cart
29	7942-1	2Way Locking Cntr F	$1.87	Add to Cart
30	5940-5	1614 GA Spg Loaded Term M	$1.75	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F032	1420x34 Hex Bolt	$0.50	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F061	14 Star Lock Wshr	$0.18	Add to Cart
	F068	18x1 Cotter Pin	$0.18	Add to Cart
	F069	332x12 Cotter Pin	$0.18	Add to Cart
	F093	51618x1 Hex Bolt	$0.94	Add to Cart
	F134	AN960816L Washer	$0.65	Add to Cart
	F179	1420x1 Hex Bolt	$0.65	Add to Cart
	F316	51618x134 Hex Bolt	$1.08	Add to Cart
	F320	18x34 Split Spring Pin	$0.29	Add to Cart
