PARTS > MC MANUALS > 2024-11-14, 6000-47, Serial 183834-191078 > Rear Body Assembly (10.0):

Diagram #	Part #	Description	Price	Add to Cart
1	6515-1	Catcher Support 10BU MC23i	$213.15	Add to Cart
2	5267-1	Retainer Collar 1	$13.52	Add to Cart
3	5270-1	Ball Bearing	$9.20	Add to Cart
4	6342-1	Rear Chassis
5	7420-12	Tail Wheel Fork	$130.10	Add to Cart
6	5830-3	Grease Fitting 45 Deg	$4.04	Add to Cart
7	8039	Nut Tail Wheel Axle	$6.91	Add to Cart
8	8768-2	Seal Reverse Lip	$10.08	Add to Cart
9	8038-1	Spacer Wheel Axle 750xIDx1125OD	$12.61	Add to Cart
10	8037	Bearing Cone 34ID	$12.09	Add to Cart
11	8035-1	Wheel Tire13x456 Ply With Bearing Race	$103.57	Add to Cart
	8035-3	Tail Wheel Tire 13x456 Ply	$62.62	Add to Cart
	8036	Tail Wheel Hub 6x325 WRace	$60.14	Add to Cart
	8037-2	Bearing Race	$13.55	Add to Cart
	7420-20	Dual Tail Whl Tire Assy	$386.19	Add to Cart
12	8038	Tail Whl Axle34x1038	$62.85	Add to Cart
13	6342-7	Catcher Bumper Mount
14	5845	Rubber Bumper 150x125	$7.12	Add to Cart
15	8515-17	Catcher Handle PlateLH	$17.66	Add to Cart
16	7190-6	Insulation Foam Pad	$51.85	Add to Cart
17	7146	13mm Ball Stud	$4.92	Add to Cart
18	7147	Spring Clip	$1.44	Add to Cart
19	7145	Gas Spring Assembly	$39.60	Add to Cart
20	8515-18	Catcher Handle PlateRH	$17.69	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F032	1420x34 Hex Bolt	$0.50	Add to Cart
	F034	51618x34 Hex Bolt	$0.79	Add to Cart
	F172	1420x34 Carriage Bolt	$0.50	Add to Cart
	F218	716 Split Lock Washer	$0.34	Add to Cart
	F219	71614x114 Hex Bolt	$2.06	Add to Cart
	F226	51618x78 Hex Bolt	$0.78	Add to Cart
	F413	51624x516 Set Screw	$0.58	Add to Cart
	F569	1420 Flange Top Lock Nut	$1.20	Add to Cart
	F615	10 x 255 x 125 Washer	$2.20	Add to Cart
	F693
	F694	3816x1 Flanged Hex Bolt	$2.75	Add to Cart
	F718
