PARTS > MT MANUALS > 2017-01-12, 8000-25, Serial 134242-149092 > Rear Body Assembly (GHS Models):

Diagram #	Part #	Description	Price	Add to Cart
1	7190-3	Insl Foam PadGHS 5x20	$10.56	Add to Cart
2	8082	Heat Shield	$30.73	Add to Cart
3	8515-14	Catcher Handle Plate RH	$18.13	Add to Cart
4	8515-13	Catcher Handle Plate LH	$18.13	Add to Cart
5	8615-3	NR 100Catcher Spprt Frm TEFI	$198.56	Add to Cart
6	7190-2	Insulation Foam PadRH	$19.23	Add to Cart
7	7190-1	Insulation Foam PadLH	$24.27	Add to Cart
8	5832	Cable Clamp 12 203 Hole	$1.87	Add to Cart
9	7145	Gas Spring Assembly	$39.60	Add to Cart
10	8389-4	Splash Guard	$14.65	Add to Cart
11	7147	Spring Clip	$1.44	Add to Cart
12	7146	13mm Ball Stud	$4.92	Add to Cart
13	8105-1	NR Rear Body Panel	$86.14	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F026	1024x12 PPHMS	$0.18	Add to Cart
	F027	1024x58 PPHMS	$0.18	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F032	1420x34 Hex Bolt	$0.50	Add to Cart
	F085	316 Rivet Backup Washer	$0.44	Add to Cart
	F178	14x1 Fender Washer	$1.42	Add to Cart
	F390	1420x78 Carriage Bolt	$0.65	Add to Cart
