PARTS > MB MANUALS > 2005-12-15, 4000-2, Serial 79432-85247 > Spread Tail Wheel:

Diagram #	Part #	Description	Price	Add to Cart
1	7420-6	Washer 2 ODx 12 ID	$10.13	Add to Cart
2	5841	Retainer Washer 38x114	$1.42	Add to Cart
3	4420-5	Mount, Spread Axle
4	8769-8	Dust Cap Deck Caster	$10.62	Add to Cart
5	8769-6	Bearing Cone 1ID	$11.86	Add to Cart
6	8769-5	Bearing Cup 2x158	$7.52	Add to Cart
7	7420-4	Fork Mount Tube	$260.61	Add to Cart
8	8769-7	Seal	$5.66	Add to Cart
9	7420-2	Tail Fork Spread Axle	$108.57	Add to Cart
10	8039	Nut Tail Wheel Axle	$6.91	Add to Cart
11	8038-1	Spacer Wheel Axle 750xIDx1125OD	$12.61	Add to Cart
12	8768-2	Seal Reverse Lip	$10.08	Add to Cart
13	8037	Bearing Cone 34ID	$12.09	Add to Cart
14	8035	Tail Whl& Tire(13x5.00-6) (W/Bearing Race)	$75.08	Add to Cart
	7035-1	Tail Whl Tire 13x5006	$63.00	Add to Cart
	8036	Tail Wheel Hub 6x325 WRace	$60.14	Add to Cart
	8037-2	Bearing Race	$13.55	Add to Cart
15	8037-1	Seal- Outer (1-3/4x1-1/8)	$7.16	Add to Cart
16	7038	Wheel Axle34x5916	$43.85	Add to Cart
17	7420-7	Pivot Shaft (1 x 5-1/4)
18	5683	Pivot Bearing	$10.16	Add to Cart
19	5830	Grease Fitting 1428	$2.47	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F016	1213 SelfLocking Nut	$1.51	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F046	3816x312 Hex Bolt	$2.88	Add to Cart
	F140	71614x1 Hex Bolt	$1.87	Add to Cart
	F205	51618x14 Set Screw Knurl Point	$0.94	Add to Cart
	F218	716 Split Lock Washer	$0.34	Add to Cart
	F278	38 Split Lock Washer	$0.18	Add to Cart
	F344	3416 Slotted Hex Nut	$3.12	Add to Cart
	F347	34 SAE Washer	$1.18	Add to Cart
	F348	18x112 Cotter Pin	$0.18	Add to Cart
	F377	1213x5 Hex Bolt	$5.40	Add to Cart
