PARTS > MR MANUALS > 2022-09-22, 1000-6, Serial 174105-178454 > Steering Control Assemblies:

Diagram #	Part #	Description	Price	Add to Cart
1	5850-2	Handle Grip Foam 512	$5.45	Add to Cart
2	1170-27	FSC Lever Weldment
3	4219-1	Extension Spring	$14.54	Add to Cart
4	8655-4	Clevis Pin 516x34	$1.06	Add to Cart
5	4407-4	Bow Tie Cotter Pin	$0.68	Add to Cart
6	1170-1	FSC Link	$9.44	Add to Cart
7	4142-1	FSC Cam	$4.75	Add to Cart
8	5141	FSC Friction Washer 112x38x116 Delrin	$1.80	Add to Cart
9	2212-3	Seal Retainer	$8.86	Add to Cart
10	1212-4	Transmission Control Arm	$8.70	Add to Cart
11	5214-4	Ball Jnt 51624 WO Stud	$12.43	Add to Cart
12	2025-10	TWHCS 51624x10 Patch	$6.70	Add to Cart
13	5213-5	Control Rod 17	$12.83	Add to Cart
14	5665-1	Compression Sprg 212	$4.68	Add to Cart
15	9704-3	Pivot Rod BushingPlastic	$7.70	Add to Cart
16	5146	10mm Ball Stud	$3.77	Add to Cart
17	4199-3	Steering Lever Dampener Assy	$45.14	Add to Cart
18	5463-4	(NR) Steering Lever Actuator	$10.39	Add to Cart
19	5463-6	Washer 516x34x250	$4.70	Add to Cart
20	1451-40	Steering Assembly
21	5222	Ext Spring 12x314	$6.82	Add to Cart
22	5450	DClip	$1.54	Add to Cart
23	4452-6	Steering Pivot 1420x158	$2.71	Add to Cart
24	1452	Steering Lever Tube WTabMR	$24.24	Add to Cart
25	5453-10	Steering Lvr Handle Adj	$11.42	Add to Cart
26	7201-2	Fiberglide Bearing 12	$6.70	Add to Cart
27	5463-5	Steering Arm Pivot Bushing SS 5x313x285	$5.20	Add to Cart
28	5830	Grease Fitting 1428	$2.47	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F010	51624 ESNA Nut	$0.50	Add to Cart
	F020	51618 ESNA Nut	$0.34	Add to Cart
	F024	51624 Jam Nut	$0.34	Add to Cart
	F049	516 SAE Washer	$0.18	Add to Cart
	F093	51618x1 Hex Bolt	$0.94	Add to Cart
	F111	18x34 Cotter Pin	$0.18	Add to Cart
	F116	1420x114 Hex Bolt	$0.65	Add to Cart
	F146	1420 Jam Nut	$0.18	Add to Cart
	F183	312x700x074 Washer	$0.58	Add to Cart
	F188	1420 SelfLocking Nut	$0.30	Add to Cart
	F192	3824 SelfLocking Nut	$1.14	Add to Cart
	F198	250x625x040 WasherSS	$0.79	Add to Cart
	F226	51618x78 Hex Bolt	$0.78	Add to Cart
	F312	38x38 Shoulder Bolt	$3.50	Add to Cart
	F345	1420x770 Knurled Bolt	$1.68	Add to Cart
	F392	1420x1 Set ScrewSS Cup Point	$1.56	Add to Cart
	F407	Belleville Wshr 38x1187 SS	$4.51	Add to Cart
	F620	3824x112 Hex Bolt 781 Thread Length	$4.70	Add to Cart
