PARTS > MT MANUALS > 2024-04-08, 8000-56, Serial 187255-189967 > Steering Control Assemblies:

Diagram #	Part #	Description	Price	Add to Cart
1	6201-4	Shock Mount Gear DriveRH	$9.48	Add to Cart
2	5146	10mm Ball Stud	$3.77	Add to Cart
3	5199-4	Steering Lever Dampener Assy	$51.92	Add to Cart
4	6201-3	Shock Mount Gear Drive/LH	$7.80	Add to Cart
5	5214-2	Ball Joint 51624 Nylon Lined	$13.02	Add to Cart
6	6212-7	Transmission Control ArmLH Pump	$26.66	Add to Cart
7	5213-3	Control Rod 6	$10.44	Add to Cart
8	5665-1	Compression Sprg 212	$4.68	Add to Cart
9	7201-2	Fiberglide Bearing 12	$6.70	Add to Cart
10	5463-5	Steering Arm Pivot Bushing SS 5x313x285	$5.20	Add to Cart
11	5463-7	Steering Lever Actuator	$12.24	Add to Cart
12	5213-4	Control Rod 1434	$11.41	Add to Cart
13	5212-7	Transmission Control ArmRH Pump	$28.25	Add to Cart
14	5850-2	Handle Grip Foam 512	$5.45	Add to Cart
15	7170-2	FSC Lever Assembly	$88.52	Add to Cart
16	5830	Grease Fitting 1428	$2.47	Add to Cart
17	5975-3	Cable Tie 50x7	$0.36	Add to Cart
18	5214-4	Ball Jnt 51624 WO Stud	$12.43	Add to Cart
19	5219	Extension Spg 34x634	$6.76	Add to Cart
20	5172	Bearing Delrin 250x375x250 Length	$4.96	Add to Cart
21	5141-1	FSC Actuator Block	$10.31	Add to Cart
22	5140-9	FSC Brace	$11.82	Add to Cart
23	5141	FSC Friction Washer 112x38x116 Delrin	$1.80	Add to Cart
24	5142-8	FSC Key	$5.66	Add to Cart
	5140-25	FSC Control Assembly (Includes Items # 16, 23-25, 28,
25	5140-35	FSC Friction Body (Includes Item # 16)
26	5141-2	FSC Actuator Rod	$19.51	Add to Cart
27	5281-5	Clevis Pin 14x080	$1.37	Add to Cart
28	5142-9	FSC Actuator Cam	$29.30	Add to Cart
29	5141-3	Spacer 750x313x688	$9.61	Add to Cart
30	5141-4	FSC Rod	$4.37	Add to Cart
31	5470-2	Speed Control StopGrDrv	$37.62	Add to Cart
32	5217-1	Pivot Pin Steering Lever	$11.56	Add to Cart
33	5391-3	Steering Lever Support	$3.98	Add to Cart
34	5225-4	Extension Spring 58x2	$5.78	Add to Cart
35	5451-12	Steering Lever Assembly, LH / Adjustable (Includes Items # 2, 9-11, 16, 34,
36	5453-14	NR Steering Lever HandleADJ	$18.74	Add to Cart
37	5450-12	Steering Lever ArmRH	$131.46	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F007	51618 Jam Nut	$0.34	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F010	51624 ESNA Nut	$0.50	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F024	51624 Jam Nut	$0.34	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F031	1420x58 Hex Bolt	$0.50	Add to Cart
	F032	1420x34 Hex Bolt	$0.50	Add to Cart
	F034	51618x34 Hex Bolt	$0.79	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F051	38 SAE Washer	$0.65	Add to Cart
	F064	18x12 Woodruff Key 3	$5.45	Add to Cart
	F069	332x12 Cotter Pin	$0.18	Add to Cart
	F146	1420 Jam Nut	$0.18	Add to Cart
	F182	14x58x18 Washer	$1.20	Add to Cart
	F183	312x700x074 Washer	$0.58	Add to Cart
	F186	564x12 Cotter Pin	$0.18	Add to Cart
	F188	1420 SelfLocking Nut	$0.30	Add to Cart
	F192	3824 SelfLocking Nut	$1.14	Add to Cart
	F193	38 Belleville Spg Washer	$2.62	Add to Cart
	F198	250x625x040 WasherSS	$0.79	Add to Cart
	F226	51618x78 Hex Bolt	$0.78	Add to Cart
	F316	51618x134 Hex Bolt	$1.08	Add to Cart
	F345	1420x770 Knurled Bolt	$1.68	Add to Cart
	F350	1420 LP Nylock	$0.65	Add to Cart
	F353	3816 ESNA LP Nut	$0.50	Add to Cart
	F401	504x751x030 Washer	$0.65	Add to Cart
	F562	51618x1 Set Screw	$2.06	Add to Cart
	F582	Washer 516x78x125	$1.99	Add to Cart
