PARTS > MB MANUALS > 2024-12-19, 4000-47, Serial 184730-197179 > Steering Control Assemblies:

Diagram #	Part #	Description	Price	Add to Cart
1	5850-2	Handle Grip Foam 512	$5.45	Add to Cart
2	4170-2	FSC Lever	$31.94	Add to Cart
3	4219-1	Extension Spring	$14.54	Add to Cart
4	4170-3	FSC Linkage
5	5830	Grease Fitting 1428	$2.47	Add to Cart
6	5146	10mm Ball Stud	$3.77	Add to Cart
7	4199-4	Steering Lever Dampener Assy	$53.80	Add to Cart
8	8201-3	Fiberglide Bearing	$13.74	Add to Cart
9	5463-4	(NR) Steering Lever Actuator	$10.39	Add to Cart
10	5665-1	Compression Sprg 212	$4.68	Add to Cart
11	2213	Control Rod 7	$6.00	Add to Cart
12	2212-3	Seal Retainer	$8.86	Add to Cart
13	5214-2	Ball Joint 51624 Nylon Lined	$13.02	Add to Cart
14	6212-4	Transmission Control Arm	$9.26	Add to Cart
15	4451-16	Steering Pivot Shaft WStop	$53.33	Add to Cart
16	6451-1	Speed Control ActuatorLH MSMB	$112.67	Add to Cart
17	7201-2	Fiberglide Bearing 12	$6.70	Add to Cart
18	5463-5	Steering Arm Pivot Bushing SS 5x313x285	$5.20	Add to Cart
19	5463-6	Washer 516x34x250	$4.70	Add to Cart
20	5453-14	NR Steering Lever HandleADJ	$18.74	Add to Cart
21	6452-1	Steering Lever Tube W/Tab
22	5450	DClip	$1.54	Add to Cart
23	5222	Ext Spring 12x314	$6.82	Add to Cart
24	4452-6	Steering Pivot 1420x158	$2.71	Add to Cart
25	9704-3	Pivot Rod BushingPlastic	$7.70	Add to Cart
26	4142-2	FSC Friction Washer 112x1132x116	$3.58	Add to Cart
27	5141	FSC Friction Washer 112x38x116 Delrin	$1.80	Add to Cart
28	4142-1	FSC Cam	$4.75	Add to Cart
29	6451-4	Speed Control Actuator, RH (Includes Items # 5 & 8)
30	4451-17	FSC Friction Actuator
	F004	1420 Keps Nut	$0.34	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F008	51624 Keps Nut	$0.79	Add to Cart
	F010	51624 ESNA Nut	$0.50	Add to Cart
	F013	3816 Whiz Locknut	$0.65	Add to Cart
	F024	51624 Jam Nut	$0.34	Add to Cart
	F035	51618x114 Hex Bolt	$0.94	Add to Cart
	F044	51624x34 Hex Bolt	$0.79	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F093	51618x1 Hex Bolt	$0.94	Add to Cart
	F116	1420x114 Hex Bolt	$0.65	Add to Cart
	F146	1420 Jam Nut	$0.18	Add to Cart
	F167	51618 Hex Nut	$0.34	Add to Cart
	F173	51618x34 Carriage Bolt	$0.65	Add to Cart
	F183	312x700x074 Washer	$0.58	Add to Cart
	F188	1420 SelfLocking Nut	$0.30	Add to Cart
	F192	3824 SelfLocking Nut	$1.14	Add to Cart
	F312	38x38 Shoulder Bolt	$3.50	Add to Cart
	F385	14x114 Roll Pin	$1.14	Add to Cart
	F390	1420x78 Carriage Bolt	$0.65	Add to Cart
	F392	1420x1 Set ScrewSS Cup Point	$1.56	Add to Cart
	F407	Belleville Wshr 38x1187 SS	$4.51	Add to Cart
	F551	51618 Flange Top Lock Nut	$1.06	Add to Cart
	F571	51618x78 Carriage Bolt	$2.29	Add to Cart
	F582	Washer 516x78x125	$1.99	Add to Cart
	F620	3824x112 Hex Bolt 781 Thread Length	$4.70	Add to Cart
