Part Lookup Tool

PARTS > MC MANUALS > 2025-04-08, 6000-49, Serial 191079-AND ON > Steering Control Assemblies:

Diagram #	Part #	Description	Price	Add to Cart
1	5850-2	Handle Grip Foam 512	$5.45	Add to Cart
2	4170-2	FSC Lever	$31.94	Add to Cart
3	4219-1	Extension Spring	$14.54	Add to Cart
4	4170-3	FSC Linkage
5	5146	10mm Ball Stud	$3.77	Add to Cart
6	4199-4	Steering Lever Dampener Assy	$53.80	Add to Cart
7	5463-4	(NR) Steering Lever Actuator	$10.39	Add to Cart
8	5463-5	Steering Arm Pivot Bushing SS 5x313x285	$5.20	Add to Cart
9	7201-2	Fiberglide Bearing 12	$6.70	Add to Cart
10	4215-14	Step Washer
11	5665-1	Compression Sprg 212	$4.68	Add to Cart
12	5213-7	Control Rod (8-3/8)
13	5214-2	Ball Joint 51624 Nylon Lined	$13.02	Add to Cart
14	2212-3	Seal Retainer	$8.86	Add to Cart
15	6212-8	Transmission Control Arm, RH
16	6212-9	Transmission Control Arm, LH
17	6451-7	Steering Pivot Shaft W/Stop
18	8201-3	Fiberglide Bearing	$13.74	Add to Cart
19	5830	Grease Fitting 1428	$2.47	Add to Cart
20	6451-5	Speed Control Actuator, LH (Includes Items # 18 & 19)
21	5453-14	NR Steering Lever HandleADJ	$18.74	Add to Cart
22	5450	DClip	$1.54	Add to Cart
23	5222	Ext Spring 12x314	$6.82	Add to Cart
24	6452-1	Steering Lever Tube W/Tab
25	4452-6	Steering Pivot 1420x158	$2.71	Add to Cart
26	6451-10	Speed Control Actuator, RH (Includes Items # 18 & 19)
27	6451-9	FSC Friction Actuator
28	4142-1	FSC Cam	$4.75	Add to Cart
29	5141	FSC Friction Washer 112x38x116 Delrin	$1.80	Add to Cart
30	4142-2	FSC Friction Washer 112x1132x116	$3.58	Add to Cart
31	9704-3	Pivot Rod BushingPlastic	$7.70	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F008	51624 Keps Nut	$0.79	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F010	51624 ESNA Nut	$0.50	Add to Cart
	F024	51624 Jam Nut	$0.34	Add to Cart
	F035	51618x114 Hex Bolt	$0.94	Add to Cart
	F044	51624x34 Hex Bolt	$0.79	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F060	AN960516 Washer	$0.29	Add to Cart
	F146	1420 Jam Nut	$0.18	Add to Cart
	F167	51618 Hex Nut	$0.34	Add to Cart
	F169	51618x1 Carriage Bolt	$0.79	Add to Cart
	F183	312x700x074 Washer	$0.58	Add to Cart
	F188	1420 SelfLocking Nut	$0.30	Add to Cart
	F192	3824 SelfLocking Nut	$1.14	Add to Cart
	F211	1420x78 Hex Bolt	$0.65	Add to Cart
	F312	38x38 Shoulder Bolt	$3.50	Add to Cart
	F385	14x114 Roll Pin	$1.14	Add to Cart
	F390	1420x78 Carriage Bolt	$0.65	Add to Cart
	F392	1420x1 Set ScrewSS Cup Point	$1.56	Add to Cart
	F407	Belleville Wshr 38x1187 SS	$4.51	Add to Cart
	F456	51618x34 SBH Cap Screw SS	$1.97	Add to Cart
	F551	51618 Flange Top Lock Nut	$1.06	Add to Cart
	F571	51618x78 Carriage Bolt	$2.29	Add to Cart
	F620	3824x112 Hex Bolt 781 Thread Length	$4.70	Add to Cart
