PARTS > MC MANUALS > 1997-11-05, 6000-5, Serial 31040-49732 > Suspension Seat Kit:

Diagram #	Part #	Description	Price	Add to Cart
1	6103-92	Armrest/RH/SS	$74.71	Add to Cart
2	NS	5/8NutCover
3	NS	7/16-20 x 13/4 HHCS
4	NS	3/8 SAE Washer
5	NS	Bushing, 3/4 x 3/4
6	6103-91	Armrest/LH/SS	$74.71	Add to Cart
7	6103-11	Suspension Seat
8	5941-5	Safety Switch NO	$72.28	Add to Cart
9	6103-33	Seat Mount PlateLHSS	$17.07	Add to Cart
10	7223	Compression Spring (1/2 x 1)
11	5975-3	Cable Tie 50x7	$0.36	Add to Cart
12	5975-1	Cable Tie 18x334	$0.34	Add to Cart
13	6103-23	Wire HarnessSS	$18.44	Add to Cart
14	7846	Washer 38x114x18	$8.06	Add to Cart
15	7204	Shoulder Bolt Seat Mount	$7.07	Add to Cart
16	5453-20	NR Steerng Lvr Hndl1AdjSS	$12.54	Add to Cart
17	5977-6	Grommet 1x114	$1.26	Add to Cart
18	5841	Retainer Washer 38x114	$1.42	Add to Cart
19	7845	Rubber Bumper 1375X63	$4.80	Add to Cart
20	7440-5	Shock Mount 114x34	$8.21	Add to Cart
21	6103-34	Seat Mount PlateRHSS	$17.07	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F009	51618 Whiz Locknut	$0.50	Add to Cart
	F026	1024x12 PPHMS	$0.18	Add to Cart
	F168	516 Split Lock Washer	$0.18	Add to Cart
	F227	38x114x18 Plastic Shoulder Washer	$8.10	Add to Cart
	F357	M8x16 Hex Bolt	$1.20	Add to Cart
	F358	M8x25 Hex Bolt	$1.30	Add to Cart
