Part Lookup Tool

PARTS > MD MANUALS > 2007-09-15, 7000-10, Serial 92037-103913 > Tail Wheel Lock Kit:

Diagram #	Part #	Description	Price	Add to Cart
1	5995-2	Switch Boot	$5.26	Add to Cart
2	8547	Switch Mount	$6.10	Add to Cart
3	8555	NR Decal Tail Whl LockLex	$10.10	Add to Cart
4	5995	Toggle Switch OffOn	$14.16	Add to Cart
5	7942-4	NR Single Connector M	$2.71	Add to Cart
6	5940-4	1614 GA Spg Ldd TermF	$1.67	Add to Cart
7	5977-2	Grommet Cut 18x38	$1.20	Add to Cart
8	5975-3	Cable Tie 50x7	$0.36	Add to Cart
9	8550	Wire Harness Tail Wheel Lock	$53.02	Add to Cart
10	5975-1	Cable Tie 18x334	$0.34	Add to Cart
11	8553	Splice Tap 1814Ga	$0.94	Add to Cart
12	8543	Solenoid Mount	$57.88	Add to Cart
13	5830-3	Grease Fitting 45 Deg	$4.04	Add to Cart
14	8551	Ground Wire	$7.56	Add to Cart
15	8546	Solenoid Control Module	$151.52	Add to Cart
16	5996	14x1614 GA QDF Terminal Fully Insulated	$1.18	Add to Cart
17	8552	Cnctr Plug Wire Assy	$11.11	Add to Cart
18	8544	Clevis 916	$22.15	Add to Cart
19	5551-1	Pivot Bearing S3PP	$5.20	Add to Cart
	8545-1	Pivot Bearing Assembly	$20.15	Add to Cart
20	8544-1	Bearing Spcr 14IDx916	$15.11	Add to Cart
21	8542	NR Tail Wheel Fork Locking	$111.30	Add to Cart
22	8944	NR 3Way Locking Conn M	$1.32	Add to Cart
23	8944-1	NR 3Way Locking Conn F	$1.98	Add to Cart
24	5940-5	1614 GA Spg Loaded Term M	$1.75	Add to Cart
25	5996-13	1614 GA Ring Term10 Insulated	$0.94	Add to Cart
26	7929	NR Actuating Solenoid	$116.45	Add to Cart
27	8549	Sleeve Delrin	$8.40	Add to Cart
28	8541	Plunger Rod	$6.62	Add to Cart
	8554	NR Solenoid Mount Assembly	$513.24	Add to Cart
29	7941-4	Circuit Breaker25AMP	$11.33	Add to Cart
30	7854	Plastic TipRed	$0.50	Add to Cart
31	6541-2	Blower Lockout Rod	$13.16	Add to Cart
32	6541-1	Blower Lockout Latch	$6.26	Add to Cart
33	5280	Clevis 14	$13.52	Add to Cart
34	5281-5	Clevis Pin 14x080	$1.37	Add to Cart
35	6541-3	Blower Lockout Pivot Arm	$6.82	Add to Cart
36	6541-4	Blower Lockout Belt Guide	$8.06	Add to Cart
37	7542-6	Blower Scroll (10.5) (Includes Item # 38)
38	6542-50	Decal, ?H? (5/8)
	F002	1024 Keps Nut	$0.18	Add to Cart
	F003	1428 Hex Nut	$0.18	Add to Cart
	F004	1420 Keps Nut	$0.34	Add to Cart
	F012	3816 Keps Nut	$0.79	Add to Cart
	F026	1024x12 PPHMS	$0.18	Add to Cart
	F029	1420x12 Hex Bolt	$0.50	Add to Cart
	F032	1420x34 Hex Bolt	$0.50	Add to Cart
	F038	3816x1 Hex Bolt	$1.06	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F091	51618x58 Hex Bolt	$0.65	Add to Cart
	F134	AN960816L Washer	$0.65	Add to Cart
	F179	1420x1 Hex Bolt	$0.65	Add to Cart
	F186	564x12 Cotter Pin	$0.18	Add to Cart
	F190	#10 Internal Star Lock Washer
	F198	250x625x040 WasherSS	$0.79	Add to Cart
	F298	3824 Jam Nut	$0.65	Add to Cart
	F299	1024x1 PPHMS	$0.36	Add to Cart
	F300	1015x1500x031 Washer	$3.98	Add to Cart
	F325	1420x3 Hex Bolt	$1.18	Add to Cart
	F350	1420 LP Nylock	$0.65	Add to Cart
