PARTS > MD MANUALS > 1998-01-20, 7000-2, Serial 29676-60191 > Throttle Control Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	5832	Cable Clamp 12 203 Hole	$1.87	Add to Cart
2	7220	Throttle Cable	$178.92	Add to Cart
3	NS	10-32 Jam Nut
4	5150	Ball Joint 1032	$7.01	Add to Cart
5	5108-7	Control Lock Tab	$2.52	Add to Cart
6	5108-10	Friction Washer 125	$1.98	Add to Cart
7	5108-1	Control LeverThrottleChoke	$4.44	Add to Cart
8	5108-5	NR Throttle Cntrl KnobRed	$6.05	Add to Cart
9	5108-11	Friction Washer 062	$1.44	Add to Cart
10	5108-8	Control Bracket	$9.26	Add to Cart
11	7111	NR Choke Mount Bracket	$6.26	Add to Cart
12	7109	Choke Control Cable	$37.11	Add to Cart
13	7128	Control Bracket	$10.32	Add to Cart
14	7110	NR Throttle Control Assembly	$22.84	Add to Cart
	7108	Control Assembly	$30.21	Add to Cart
15	7113	NR Throttle CntrlCable Assy	$175.35	Add to Cart
16	7112	NR Throttle CntrlCable Assy	$221.97	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F072	14 E Retainer Ring	$0.34	Add to Cart
	F079	66AAD Alum Pop Rivet 316 Diax 38 Grip	$0.65	Add to Cart
	F201	SU F642 1 4 Belleville Spg Washer	$1.75	Add to Cart
	F260	M4x7x6 PPHMS	$0.34	Add to Cart
	F232	1032 Keps Nut	$0.50	Add to Cart
