PARTS > MC MANUALS > 1997-02-07, 6000-2, Serial 08613-32625 > Throttle and Choke Control Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	5832	Cable Clamp 12 203 Hole	$1.87	Add to Cart
2	5975-2	Cable Tie (30# x 6?)
3	5108-3	NR Throttle Cable 64	$20.48	Add to Cart
4	5108-4	NR Choke Cable 71	$18.77	Add to Cart
5	5172	Bearing Delrin 250x375x250 Length	$4.96	Add to Cart
6	5108-7	Control Lock Tab	$2.52	Add to Cart
7	5108-10	Friction Washer 125	$1.98	Add to Cart
8	5108-1	Control LeverThrottleChoke	$4.44	Add to Cart
9	5108-5	NR Throttle Cntrl KnobRed	$6.05	Add to Cart
10	5108-11	Friction Washer 062	$1.44	Add to Cart
11	5108-8	Control Bracket	$9.26	Add to Cart
12	7108	Control Assembly	$30.21	Add to Cart
13	5108-6	NR Choke Cntrl KnobBlack	$5.74	Add to Cart
14	NS	Wire Nut (Kohler)
15	6108	NR Throttle CntrlCable Assy	$63.97	Add to Cart
16	6109	NR Choke Cntrl Cable Assy	$76.31	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F164	1024x14x38 SHL Bolt	$2.95	Add to Cart
	F201	SU F642 1 4 Belleville Spg Washer	$1.75	Add to Cart
