PARTS > MC MANUALS > 2003-11-01, 6000-9, Serial 60467-66219 > Throttle and Choke Control Assembly:

Diagram #	Part #	Description	Price	Add to Cart
1	8121-1	Throttle Cable 445	$21.08	Add to Cart
2	8122-1	Choke Cable 505	$21.69	Add to Cart
3	5172	Bearing Delrin 250x375x250 Length	$4.96	Add to Cart
4	5108-7	Control Lock Tab	$2.52	Add to Cart
5	5108-10	Friction Washer 125	$1.98	Add to Cart
6	5108-1	Control LeverThrottleChoke	$4.44	Add to Cart
7	5108-5	NR Throttle Cntrl KnobRed	$6.05	Add to Cart
8	5108-11	Friction Washer 062	$1.44	Add to Cart
9	5108-8	Control Bracket	$9.26	Add to Cart
10	7108	Control Assembly	$30.21	Add to Cart
	8121	Throttle CntrlCable Assy	$64.97	Add to Cart
	8122	Choke Cntrl Cable Assy	$65.63	Add to Cart
11	5108-6	NR Choke Cntrl KnobBlack	$5.74	Add to Cart
12	8123	Insulating Sleeve 38x6	$3.26	Add to Cart
13	5975-3	Cable Tie 50x7	$0.36	Add to Cart
14	5975-1	Cable Tie 18x334	$0.34	Add to Cart
	F002	1024 Keps Nut	$0.18	Add to Cart
	F005	1420 ESNA Nut	$0.34	Add to Cart
	F025	1024x38 PPHMS	$0.18	Add to Cart
	F050	14 SAE Washer	$0.18	Add to Cart
	F164	1024x14x38 SHL Bolt	$2.95	Add to Cart
	F201	SU F642 1 4 Belleville Spg Washer	$1.75	Add to Cart
